LIVEGRADE

ALL DEVICE INTEGRATIONS

Livegrade supports a wide range of devices that interact with the software. As they are of different product types Livegrade offers different integrations for the different types of devices.

The device types are:

LUT BOXES

This type of devices is used for interactive look control of an HD-SDI stream. They usually have an in- and output to route the signal through the box. Livegrade connects to them to manipulate the look of the image.

FS-HDR BY AJA

CONNECTIVITY___Ethernet

LUT SIZE___Large

EXTRAS___Interactive grading in 4K (“Single Channel”) and 4xHD (independent “Multi-Channel”)

NOTES___Powerful image processor e.g. with built in HDR/SDR conversions

“Dynamic LUT” mode (LUT box interaction) supported in Livegrade Pro and Livegrade Studio. “Colorfront Film” mode only available in Livegrade Studio.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

BOXIO BY FLANDERS SCIENTIFIC (FSI)

CONNECTIVITY___Ethernet, Wifi

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode, Camera Metadata*

NOTES___Two separate signal chains possible, clean loop through, scopes

Best suitable for advanced setups. Control two independent channels in one device. Highly flexible product for a broad range of use cases.

* Camera Metadata is only supported on channel 1

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

BOXIO LITE SDI BY FLANDERS SCIENTIFIC (FSI)

CONNECTIVITY___Ethernet, Wifi

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode, Camera Metadata

NOTES___Clean loop through

Best suitable for advanced setups. Control two independent channels in one device. Highly flexible product for a broad range of use cases.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

COLR BY TERADEK

CONNECTIVITY___Wifi, Ethernet,USB

LUT SIZE___Large

NOTES___Wireless control

Best suitable for advanced setups that have to be flexible and control color from distance. Highly flexible product for a broad range of use cases.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

COLR DUO BY TERADEK

CONNECTIVITY___Wifi, Ethernet,USB

LUT SIZE___Large

NOTES___Wireless control, two channels

Best suitable for advanced setups that have to be flexible and control color from distance. Highly flexible product for a broad range of use cases.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

IS-MINI BY TVLOGIC

CONNECTIVITY___USB

LUT SIZE___Medium

EXTRAS___Timecode

NOTES___Pyramidal LUT interpolation

Best suitable for more advanced setups. High quality LUT interpolation.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

IS-MINI X BY TVLOGIC

CONNECTIVITY___USB

LUT SIZE___Medium

EXTRAS___ Frame Grab, Timecode, Camera Metadata

NOTES___4k with rack, pyramidal LUT interpolation

Best suitable for more advanced setups. High quality processing for users that need precise color reproduction.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

IS-MINI 4K BY TVLOGIC

CONNECTIVITY___USB

LUT SIZE___Medium

EXTRAS___Interactive grading in 4K, Frame Grab, Timecode, Camera Metadata

NOTES___Pyramidal LUT interpolation

Best suitable for 4K setups. High quality processing for users that need precise color reproduction. Frame grab only recommended in HD due to hardware limitations.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

9904-UDX-4K BY COBALT DIGITAL

CONNECTIVITY___Ethernet

LUT SIZE___Large

NOTES___Up/Down/Cross Converter/Frame Sync for 12G/6G/3G/HD/SD UHD

Best suitable for facilities and studios with existing OpenGear infrastructure.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

MONITORS

This type of devices is used for interactive look control of the image directly on the monitor. The monitors have the processing power of the LUTbox built inside. Livegrade connects to the monitor to manipulate the look of the image.

DM170 / DM240 / CM250 BY FLANDERS SCIENTIFIC (FSI)

CONNECTIVITY___Ethernet

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode

NOTES___Clean loop through, scopes

Best suitable for compact viewing setups. No additional LUT box required to control color directly on the monitor.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

DP-V1710 / V1711 / V2410 / V2411 / V2420 / V2421 / V3010 BY CANON

CONNECTIVITY___Ethernet

LUT SIZE___Medium

EXTRAS___Frame Grab

NOTES___Dual input mode (side-by-side)

Reference monitor for compact, high-quality setups. No additional LUT box required to control color directly on the monitor.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

4K PRODUCTION MONITORS BY SMALLHD

DEVICES___Vision 24, Vision 17, OLED 22, Cine 24

CONNECTIVITY___Ethernet

LUT SIZE___Large

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

CAMERAS

This type of devices is used for interactive look control of the output signal of the camera. The cameras have the processing power built inside. Livegrade connects to the camera to manipulate the look of the camera output image.

ALEXA SXT W / ALEXA SXT BY ARRI

CONNECTIVITY___Ethernet

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode

NOTES___Look embedded in recorded clips

Best suitable for high-end setups with advanced look workflows. Directly control the look on the camera output through Livegrade.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

ALEXA MINI BY ARRI

CONNECTIVITY___Ethernet, Wifi

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode, Camera Metadata

NOTES___Look embedded in recorded clips

Best suitable for high-end setups with advanced look workflows. Directly control the look on the camera output through Livegrade.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

ALEXA 65 BY ARRI

CONNECTIVITY___Ethernet

LUT SIZE___Large

EXTRAS___Frame Grab, Timecode

NOTES___Look embedded in recorded clips

Best suitable for high-end setups with advanced look workflows. Directly control the look on the camera output through Livegrade.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

VARICAM 35 / HS / PURE / LT BY PANASONIC

CONNECTIVITY___Ethernet

LUT SIZE___Small

Control the look directly in the camera through Livegrade.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

MONSTRO 8K VV / HELIUM 8K S35 BY RED

CONNECTIVITY___Ethernet, Wifi

EXTRAS___Camera Metadata

NOTES___Hybrid workflow with LUT box and look upload

Best suitable for advanced look workflows. Directly control the look on the camera output through Livegrade.

Manufacturer Website

MILLENNIUM DXL2 BY PANAVISION

CONNECTIVITY___Ethernet, Wifi

EXTRAS___Camera Metadata

NOTES___Hybrid workflow with LUT box and look upload

Best suitable for high-end setups with advanced look workflows. Directly control the look on the camera output through Livegrade.

FURTHER READING___
Manufacturer Website

VENICE 2 BY SONY

CONNECTIVITY___Ethernet, Wifi

LUT SIZE___Large

NOTES___Look embedded in recorded clips

Best suitable for advanced look workflows. Control the ASC-CDL based look directly in the camera through Livegrade or upload looks as 3D LUTs.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

F65 BY SONY

CONNECTIVITY___Ethernet

LUT SIZE___Large (in-camera only)

NOTES___–

Control the ASC-CDL based look directly in the camera through Livegrade.

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website

CAMERA EXTENSION MODULES

This type of devices is used as an extension to the camera. Livegrade can connect to the extension module to interactively control the look of the image on the output signal.

OMOD BY TERADEK

CONNECTIVITY___Wifi

LUT SIZE___Large

NOTES___Two independent output channels

Best suitable for advanced setups. Option for controlling two independent channels with one device. High-quality product for a broad range of use cases.

FURTHER READING___
Manufacturer Website

VIDEO ROUTERS

Livegrade can automate video router configurations. This can be used to route camera signals to the monitor depending on the selected slot, or to feed signals of different cameras to one capture device.

KUMO BY AJA

CONNECTIVITY___Ethernet

Best suitable for multi-camera setups for flexible signal routing controlled automatically through Livegrade. Fan-less product options available.

FURTHER READING___
Manufacturer Website

SMART VIDEOHUB BY BLACKMAGIC DESIGN

CONNECTIVITY___Ethernet

Best suitable for multi-camera setups for flexible signal routing controlled automatically through Livegrade.

FURTHER READING___
Manufacturer Website

CAPTURE DEVICES

This type of devices is used for capturing signals to store frame grabs and look references in Livegrade.

IO SERIES BY AJA

DEVICES___Io 4k Plus, Io 4k, Io XT

CONNECTIVITY___Thunderbolt 2, Thunderbolt 3 (Io 4k Plus)

EXTRAS___Camera Metadata, Auto-Record for ARRI, RED and Sony cameras via HANC

NOTES___The Io 4K Plus is actually capable of using one single link 6G input and one single link 6G output, but the current integration only supports 3G (HD-SDI) on all four connectors

FURTHER READING___
In-Depth Knowledge Base Article
Manufacturer Website
